Low Frequency, Active Monopole Antenna ideal for low frequency measurements. |
|
|
Frequency Range: |
100 Hz - 60 MHz |
|
Antenna Factor: |
0 dB |
|
Impedance: |
50 W |
|
Pattern Type: |
omni-directional |
|
Connector: |
BNC-Type, female |
|
Mounting Base: |
¼ - 20 Thread, female |
|
Physical Dimensions: |
|
|
Ground Plane Dimensions: |
18 in. X 18 in. (45.7 cm x 45.7 cm) |
|
Rod Length: |
8.5 in. - 43 in. (21.6 cm x 109.2 cm) |
|
Weight: |
4.7 lb.'s (2.13 kg) |
|
|
|
|
Supplied Accessories |
|
|
Battery Charger (P/N: 2351) | |
|
Telescoping Rod (P/N: 2337-1) | |
Features
- Frequency Range of 100 Hz to 60 MHz
- Individually Calibrated (Calibration included per ARP-958)
- FCC, MIL-STD, VDE and TEMPEST Testing
- High Sensitivity
- Battery Pack and Charger
A.H. Systems' Active Monopole Antenna provides superior performance in electric field measurements. The Active Monopole Antenna can drive any receiver with 50 ohm input impedance and will perform FCC, MIL-STD and TEMPEST tests. The SAS-550-2 includes a battery pack and charger for open field test sites that may not have ready access to outlets.
Recommended Accessories
- ATU-510 (Antenna Tripod Unit, wooden)
- AEH-510 (Azimuth and Elevation Head, Plastic)
- SAC-210 (3 meter BNC/BNC Cable, RG-58A/U)
- ADP-201 (BNC(f) to N(m) Adapter
- P/N: 2236-24 24" x 24" (61cm x 61cm) Ground Plane
- ECF-10 (Capacitance Fixture, 10pF)
