Shielded doors for the use in faraday cages and shielded room用于法拉第箱体和屏蔽室的屏蔽门

We are specialised in designing and manufacturing standard and custom doors for shielded rooms and Faraday cages. High performance single and double knife fingerstrip doors in sliding, swing and even double swing implementations belong to the possibilities. Our engineers will assist to find the best solution possible.

We also produce sets to shield doors with gaskets on top and sides, while the bottom is provided with a conductive copper brush and doorstep. See standard modified doors.

Nearly each type of door can be provided in swings implementation or a sliding implementation.

我们是专业设计和制造标准的和定制的门用于屏蔽室和法拉第箱体。高性能单和双刀指形簧片门以滑动，旋转，甚至双旋转实施是可能的。我们的工程师将帮助找到最好的解决可能。

我们也生产成套的在顶部和侧边带有垫圈的屏蔽门，此时底部提供带有一个导电的铜刷和门阶。看标准改进的门。

几乎每个类型的门都能提供滑动或旋转的式样。

The fully automatic shielded sliding doors are designed for RF and EMP-tight enclosures. It can be integrated in shielded rooms as well as for other types of shielding.
全自动屏蔽滑动门设计用于RF和EMP紧凑壳体。它也能被集成在屏蔽室以及用于其它类型的屏蔽。
The opening procedure of the sliding door is performed in two steps:
屏蔽门的打开程序要执行两个步骤：

1. Unlatching of the contact spring system and outward movement;拔掉接触弹簧系统的门栓，往外移动。
2. Sideway movement of the door leaf.侧向移动门扇。

The movements of the door and ramp are fully automatic; they are operated electrically and pneumatically. Each opening and closing of the door has a self-cleaning effect on the contact surfaces (Fingerstrips and knife of the door). Sizes range from 1 x 2.1 meters to a 'jumbo' door of 8 x 12 meters.
门和滑行台的移动是全自动的，由电和气动操作。每次打开和关闭门有一个自清洁作用在接触表面上（门的指形簧片和刀）。尺寸范围从1 x 2.1米到一个8 x 12米的庞大的门。

Options选件

1. Fire proof火证明
2. Automatic closing自动关闭
3. Gas tight气密
4. (Automatic自动) locking system锁闭系统
5. Sound proof声音证明
6. Clean room specifications洁净室规格

Types类型

1. Single fingerstrip door单指形簧片门
   (Fingerstrip door with soldered fingers or with clamped fingers指形簧片门带有焊接指形或带有固支指形)
2. Double fingerstrip door双指形簧片门
   (Heavy duty fingerstrip door重型指形簧片门)
3. Standard modified door with gaskets标准改进门带有垫圈
   (Copper plated wooden door, with copper brush and copper doorstep铜板木质门，带有铜刷和铜门阶)

For shielding performance of the different doors which are deliverable click here
对于不同门的屏蔽性能可获得
Movie of a copper plated wooden sliding door in working action:

Swing doors双开式门

The fingerstrip swing doors are well known for their high shielding performance and are used in prefab cages as well as in our Mu-Copper systems. We manufacture single fingerstrip doors for medium shielding performance and double fingerstrip doors for high shielding performance (reduction up to 140 dB). Delivery from stock in various dimensions. In EMC applications, ferrite tiles can be affixed to the standard door leaf.
指形簧片双开式门是众所周知的它们的高屏蔽性能和被使用在预制箱体里也用在我们的钼-铜系统。我们制造单指形簧片门用于中等屏蔽性能和双指形簧片门用于高屏蔽性能（减少可到140 dB）。可从库存中交付各种尺寸的门。在EMC应用方面，铁氧体瓦片能被贴上标准的门扇上。
Options选件

1. Fire proof防火
2. Automatic closing自动关闭
3. Gas tight气密
4. (Automatic自动) locking system锁闭系统
5. Sound proof声音证明
6. Clean rooms specifications洁净室规格

To achieve the attenuation levels required, we have several types of swing door in our assortment.
为实现衰减级别的需要，我们有几个类型的双开式门在我们的分类里。
Types类型

1. Single fingerstrip door单指形簧片门
   (Fingerstrip door with soldered fingers or with clamped fingers指形簧片门带有焊接指形或带有固支指形)
2. Standard performance door for hospital use标准性能门用于医院使用
3. Standard modified door标准改进门
   (Copper plated wooden door, with copper brush and copper doorstep铜板木质门，带有铜刷和铜门阶)

For shielding performance of the different doors which are deliverable click here
不同门的屏蔽性能可获得
Standard Sizes标准尺寸

Standard shielded leaf doors in steel/wood or steel frames标准屏蔽叶门用钢/木或钢支架
Width宽度: single单 800 / 1200 mm , double双1500 / 2000 mm
Height高度: 2000 / 2100 / 2500 mm

Shielding performance of all shielding doors
