The 8200 series connector gaskets are die-cut gaskets for EMI shielding and grounding of a wide range of connectors. These new connector gaskets are more effective in closing gaps caused by fabrication tolerances and misaligned or irregular surfaces than would be possible with a solid flange design.
8200系列连接器垫圈是冲切垫圈用于EMI屏蔽和接地的一个宽系列的连接器。这些新的连接器垫圈是更加有效的在闭合由制造公差和方向偏离或非正则曲面引起的间隙比可能的带一个实心的凸缘设计。
The 8200 series is made of die-cut Amucor-shield 6800 or conductive textile, 1 or 2 mm thick, provided with self-adhesive.
8200系列由冲切的Amucor-shield 6800或导电织物制造，1或2mm厚，供应带自粘。
|
Standard dimensions标准尺寸
Sub-D connector gaskets连接器垫圈
|
Dimensions in mm尺寸用毫米
|
Front Mounting正面安装 |
Rear Mounting背面安装 |
|
Shell size |
E |
F |
G |
H |
L |
K |
L |
K |
|
9 |
33.35 |
25.00 |
19.05 |
3.56 |
19.86 |
11.43 |
16.89 |
9.40 |
|
15 |
41.68 |
33.33 |
19.05 |
3.56 |
28.20 |
11.43 |
25.22 |
9.40 |
|
25 |
55.58 |
47.04 |
19.05 |
3.56 |
41.91 |
11.43 |
38.94 |
9.40 |
|
37 |
71.86 |
63.50 |
19.05 |
3.56 |
58.37 |
11.43 |
55.40 |
9.40 |
|
50 |
69.60 |
61.11 |
21.85 |
3.56 |
55.88 |
16.82 |
53.01 |
12.19 |  |
|
RF connector gasket连接器垫圈
|
Connector
Type连接器类型
|
Dimensions in mm尺寸 |
|
A |
B |
C |
D |
|
BN |
17.45 |
12.70 |
11.10 |
2.77 |
|
BNC |
17.45 |
12.70 |
11.10 |
2.77 |
|
C |
25.40 |
18.26 |
15.88 |
4.37 |
|
HN |
30.18 |
23.01 |
19.05 |
3.56 |
|
LC |
50.80 |
36.50 |
31.75 |
6.53 |
|
N |
25.40 |
18.26 |
15.88 |
4.37 |
|
UHF |
32.54 |
24.61 |
25.40 |
4.37 |  |
|
JT, PT, PC, MIL-C-26482, MS-3110, MS-3112, MS-3119, MS-3120 connector gaskets连接器垫圈
|
Part Number /Shell Size
零件号/外壳尺寸
|
Dimensions in mm尺寸 |
|
A |
B |
C |
D |
|
8206 |
17.48 |
11.91 |
9.53 |
3.30 |
|
8208 |
20.62 |
15.09 |
12.70 |
3.30 |
|
8210 |
23.83 |
18.26 |
15.88 |
3.30 |
|
8212 |
26.19 |
20.65 |
19.05 |
3.30 |
|
8214 |
28.56 |
23.01 |
22.23 |
3.30 |
|
8216 |
30.96 |
24.61 |
25.40 |
3.30 |
|
8218 |
33.32 |
27.00 |
28.56 |
3.30 |
|
8220 |
36.53 |
29.36 |
31.75 |
3.30 |
|
8222 |
39.70 |
31.75 |
34.93 |
3.30 |
|
8224 |
42.88 |
34.93 |
38.10 |
3.96 |  |
|
AN, HT, QWL, MIL-C-5015, MS3100, MS3102 ,connector gaskets A Series
|
Part Number /
Shell Size
|
Dimensions in mm |
|
A |
B |
C |
D |
|
8208A |
22.23 |
15.09 |
12.70 |
4.37 |
|
8210A |
25.40 |
18.28 |
15.88 |
4.37 |
|
8212A |
29.79 |
20.65 |
19.05 |
4.37 |
|
8214A |
30.16 |
23.01 |
22.23 |
4.37 |
|
8216A |
32.54 |
24.61 |
25.40 |
4.37 |
|
8218A |
34.93 |
27.00 |
28.56 |
5.15 |
|
8220A |
38.10 |
29.36 |
31.75 |
5.15 |
|
8222A |
41.28 |
31.75 |
34.93 |
5.15 |
|
8224A |
44.45 |
34.93 |
38.10 |
5.15 |
|
8228A |
50.80 |
39.70 |
44.45 |
5.15 |
|
8232A |
57.15 |
44.45 |
50.80 |
5.56 |
|
8236A |
63.50 |
49.23 |
55.58 |
5.56 |
|
8240A |
69.85 |
55.58 |
61.93 |
5.56 |
|
8244A |
76.20 |
60.33 |
70.64 |
5.56 |
|
8248A |
82.55 |
66.68 |
76.99 |
5.56 |  |
|
Bendix-SP connector gasket B series
|
Part Number /Shell Size
|
Dimensions in mm |
|
A |
B |
C |
D |
|
8206B |
24.21 |
16.28 |
9.53 |
4.06 |
|
8208B |
26.59 |
18.64 |
12.70 |
4.06 |
|
8210B |
28.56 |
20.62 |
15.88 |
4.06 |
|
8212B |
31.75 |
23.83 |
19.05 |
4.06 |
|
8214B |
34.93 |
26.19 |
22.23 |
4.06 |
|
8216B |
36.50 |
28.56 |
25.40 |
4.06 |
|
8218B |
38.51 |
30.56 |
28.56 |
4.06 |
|
8220B |
42.47 |
32.94 |
31.75 |
4.06 |
|
8222B |
44.45 |
34.93 |
34.93 |
4.06 |  |
Example举例
Connector gasket 8208A with an Amucor foil (A) covering, 1mm thick
连接器垫圈8208A带一个Amucor薄板（A）覆盖，1mm厚。
Part number零件号 |
Covering覆盖 |
Thickness (mm)厚度 |
|
8208A |
A |
1 |
|
Select the partnumber form the connector gasket partnumber tables
选择零件号从连接器垫圈表。 |
T : Conductive textile导电织物
A : Amucor foil薄片
B : Embossed Amucor foil装饰Amucor薄片 |
Standard 1 or 2 mm. Other thickness on request
标准1或2mm。其它厚度根据需求。 |
